XB-SM5-186PL2-40-3| Product ID | Product Image | Product Description | Product Code | Production status | Shipping Cycle | Gross item weight | MPQ | MOQ | Production in transit | Competitive purchases | Operation |
XB-SM5-186PL2-40-3  3D
 Drawings |
 |
19.8 * 6.4 * 10.7mm medium rate micro switch DIP/with spring clip press micro switch direct insertion/reset switch/small switch 5A 125V AC/travel switch vertical plug-in/normally open switch/normally closed switch 2PIN | Normal | 1 week | 1.395 | 1000 | 20000 | 10000 | No competing products |
| Product material | 1. Microswitch | PA66 |
| 2. Seal ring | Silica gel | |
| 3. The foundation | Brass+PA66 | |
| 4. Material | POM | |
| 5. Touch moves the pad | C5191+AgNi10 | |
| 6. The five metals | SUS301-H | |
| Product type features | Type of actuator: | Control lever, normal |
| Switch type: | inches switch | |
| Usage temperature range: | -25℃ to +85℃ | |
| structural property | Configuration (extreme throw): | Unipolar-double throw |
| Electrical features | rated current (A): | 3A 5A |
| Rated voltage (VAC): | 125 250V AC | |
| lasting quality | Load-free life: | 100,000 cycles 1Ω max. |
| Load life (maximum rated load): | 100,000 cycles 1Ω max. | |
| Contact features | Terminal substrate: | yellow metal |
| Switch terminal plating material: | Nickel base gilt | |
| Terminal Current Rating Value (A): | 3A/5A | |
| machine accessory | Installation Type: | printed circuit board |
| Installation Angle: | right angle | |
| Operation / application | Operation force: | 30±30gf |
| welding condition | ||
| When automatically immersed in welding | preheat temperature | 100±10℃ |
| Preheat temperature time | 60s max. | |
| welding temperature | 260±5℃ | |
| Welding impregnation time | 5±1s | |
| Hand welding | welding temperature | 300±10℃ |
| weld period | 3+1/0s | |
